THERMAL INKJET PRINTING
High-Resolution Printing for Real Production
GT Series™ thermal inkjet printers deliver reliable, high-resolution printing for barcodes, date and batch codes, logos, SKU information, and more. With configurable printheads and a rugged, compact design, the GT Series adapts to your production environment and print requirements.
WHY GT SERIES™?
Flexible by Design
Configurable Printing
Run printheads individually or combine them for larger print areas and varied production needs.
High-Resolution Output
Produce crisp barcodes, text, logos, and variable production data with high-resolution thermal inkjet printing.
Built For Production
Compact, rugged systems designed to integrate into a wide range of production environments.
Versatile Ink Options
Choose from a broad range of high-performance inks offering strong adhesion, vivid color, and high opacity for diverse applications.
SCREEN & SOFTWARE
Control at Your Fingertips
GT Series™ touchscreen controllers provide an intuitive interface for creating messages, managing print settings, and monitoring production. Screen size varies by configuration, giving each system a control platform suited to its capabilities.
Built-In Message Editor
Create and manage text, barcodes, GS1 codes, dates, lot codes, counters, graphics, and variable data directly from the controller.
Smart Ink Management
Automatically identifies the installed ink, optimizes print parameters, and tracks ink usage.
Production Monitoring
View printer status, printhead usage, line speed, print reports, and other production information from one interface.
MODELS
GT Series™ Configurations
GT1
Up to .5" Print Height
Compact and easy to integrate, the GT 1 delivers precise printing for best-before dates, batch codes, barcodes, and other variable product information.
GT2
Up to 1" Print Height
Run two printheads individually or combine them for larger print requirements and flexible line configurations.
GT4
Up to 2" Print Height
Configure up to four printheads individually or combine them for larger print areas and more complex production requirements.
GT1Max
1" Print Height in a Single Head
A larger-format printhead for applications requiring greater print height from a single head.
TECHNICAL SPECIFICATIONS
Engineered For
Production
Print Performance
Print Technology
HP TIJ 2.5
Print Resolution
600 DPI (vertical);
40-1200 DPI (horizontal)
Print Speed
GT 1: Up to 100 m/min
GT 2 & GT 4: Up to 200 m/min
GT Max: —
Print Content
Text, Barcodes, GS1 Codes, Dates, Lot Codes, Counters, Graphics, and Variable Data
Print Height
GT 1: 0.5" (12.7 mm)
GT 2: 1" (25.4 mm)
GT 4: 2" (50.8 mm)
GT Max: .91"
Control & Integration
Controller
Capacitive Touchscreen
Ink Management
Automatic Ink Recognition and Usage Tracking
Connectivity
Ethernet, USB, External I/O
Touchscreen Size
GT 1 & GT 2: 7.1"
GT 4: 10.1"
GT Max: —
Print Capabilities
Standard Ink Colors
Black
Available Colors
Additional Colors Available
1D Barcodes
Codabar, Code 25, Code 39, Code 93, Code 128, UPC, EAN
2D Codes
QR Code, Data Matrix, MaxiCode, PDF417 + More
GS1 Support
QR Code, Data Matrix
